• Ballast-WL-811-BA
  • Product Model: Ballast-WL-811-BA

      Advantages of ballast:
      1. The conventional type ballast.
      2. Product whole potting process, mirror light stainless steel bottom cover.
      3. The working voltage 9 ~ 17 v, with open circuit protection, short circuit protection, overpressure protection, etc.
      4. The constant power output.
      5. Using the environment temperature range - 40 ℃ ~ 85 ℃.
      6. Waterproof, shockproof, satisfies the requirement of automobile and motorcycle used.
    • Introduction
    • Details
    • Specification
    Advantages of ballast:
    1. The conventional type ballast.
    2. Product whole potting process, mirror light stainless steel bottom cover.
    3. The working voltage 9 ~ 17 v, with open circuit protection, short circuit protection, overpressure protection, etc.
    4. The constant power output.
    5. Using the environment temperature range - 40 ℃ ~ 85 ℃.
    6. Waterproof, shockproof, satisfies the requirement of automobile and motorcycle used.

    Scope of application:
    This product is suitable for automobile, motorcycle headlamps modified.


            35W Mingdu hid                  55W Halogen lamp


    Model

    MDE-03-AA

    MDE-03-BA

    Specification

    12V/35W

    12V/35W

    Terminal

    AMP

    AMP

    Color

    Silver

     Black

    Input Voltage

    9~17V DC

    Start Current

    5.50±0.50A / 12V

    Stable Input Current

    3.65±0.20A / 12V

    Input High Voltage Protection

    18±0.5V

    Rated Input Power

    42.55±2.50W / 12V

    Rated Output Power

    35±2.0W / 12V

    Output Short Circuit Protection

    Automatically stop working within 0.5s while short circuit

    Output Open Circuit Protection

    Automatically stop working within 3s while open circuit

    Working Temperature

    -40℃~85℃

     lifetime

    ≥3000 hours
