• Ballast-MDE-01-BA
  • Product Model: Ballast-MDE-01-BA

      Advantages of ballast:
      1. The conventional type ballast.
      2. Product whole potting process, mirror light stainless steel bottom cover.
      3. The working voltage 9 ~ 17 v, with open circuit protection, short circuit protection, overpressure protection, etc.
      4. The constant power output.
      5. Using the environment temperature range - 40 ℃ ~ 85 ℃.
      6. Waterproof, shockproof, satisfies the requirement of automobile and motorcycle used.
    • Introduction
    • Details
    • Specification
    Advantages of ballast:
    1. The conventional type ballast.
    2. Product whole potting process, mirror light stainless steel bottom cover.
    3. The working voltage 9 ~ 17 v, with open circuit protection, short circuit protection, overpressure protection, etc.
    4. The constant power output.
    5. Using the environment temperature range - 40 ℃ ~ 85 ℃.
    6. Waterproof, shockproof, satisfies the requirement of automobile and motorcycle used.

    Scope of application:
    This product is suitable for automobile, motorcycle headlamps modified.

    HID xenon lamp and better than conventional halogen lamps for:

            35W Mingdu HID               55W Halogen Lamp


    Specification12V/35W12V/55W24V/35W24V/55W
    Input Voltage10~16V DC10~16V DC20~32V DC20~32V DC
    Start Current5.50±0.50A / 12V5.50±0.50A / 12V3±0.50A / 24V3±0.50A / 24V
    Stable Input Current3.65±0.20A / 12V4.65±0.20A / 12V1.8±0.10A / 24V2.4±0.10A / 12V
    Input High Voltage Protection18±0.5V18±0.5V34±0.5V34±0.5V
    Rated Input Power42.55±2.50W / 12V56±2.50W / 12V42.55±2.50W / 24V56±2.50W / 12V
    Rated Output Power35±2.0W / 12V50±2.0W / 12V35±2.0W / 24V50±2.0W / 12V
    Output Frequency250Hz±10%
    Air Striking Distance≥8mm
    Output Short Circuit ProtectionAutomatically stop working within 0.5s while short circuit
    Output Open Circuit ProtectionAutomatically stop working within 3s while open circuit
    Working Efficiency≥80%
    Working Temperature-40℃~85℃
    Lifetime≥3000 hours
