• H4 Lamp-H4-07
  • Product Model: H4 Lamp-H4-07

      Product features:
      1. The lights change control with spring, stainless steel spring and a solenoid valve drive with retractable bulb to achieve the level of light transformation.
      2. The electromagnetic valve actuation voltage 10 ~ 16V, light bulb changing stroke 5.5mm.
      3. bulb ambient temperature range, can work normally in -40 ℃ ~ 65 ℃.
      4. bulb adaptability, automatically adapt to the positive control and the negative positive negative positive control models.
    • Introduction
    • Details
    • Specification
    Product features:
    1. The lights change control with spring, stainless steel spring and a solenoid valve drive with retractable bulb to achieve the level of light transformation.
    2. The electromagnetic valve actuation voltage 10 ~ 16V, light bulb changing stroke 5.5mm.
    3. bulb ambient temperature range, can work normally in -40 ℃ ~ 65 ℃.
    4. bulb adaptability, automatically adapt to the positive control and the negative positive negative positive control models.
    5. lamp stability, after loading car assembly, waterproof, shockproof, meet the requirements of motor vehicles and motorcycles.
    6. The appearance of fine, stable performance, security, energy saving, long life characteristics.

    Scope of application:
    This product is suitable for all H4 type of car, motorcycle headlight assembly after the modification request.


            35W Mingdu HID               55W Halogen Lamp
    Low lights change:

    Specification12V/35W12V/55W24V/35W24V/55W
    Input Voltage10~16V20~33V
    wireH4 12V spring-type harness (or longer) + H4 spring-Controller (Controller front labeling)H4 24V spring-type harness (or longer) + H4 spring-Controller (Controller front labeling)
    Telescopic distance6mm
    Focal length32±0.3 mm /26±0.3 mm
    Bulb color temperature (K)Full range
    Working Temperature-40℃~85℃
    LifetimeRetractable lights ≥10 thousand times ≥3000 hours
